MORE FEATURES
| - 2 Year Warranty
-?Check valve on outlet
-?Ignition protected
- Handles waste water from more than one tapping point - Available in 600,750 and 1100 GPH | -?Removable mesh filter allows easy cleaning
- Clear screw-down cover
-?Easy installation
- Multiple inlet ports for versatile usage - 18AWG,1 m long Leads |
TYPICAL APPLICATIONS
Marin, Medical, Pond, Water Research, etc.
DIMENSIONS
STANDARD PUMP CONFIGURATIONS
| Model | Flow Rate | Voltage | Max Draw | Fuse Amps | Head | Wire Lead | Outlet Dia | N.W. / G.W. |
| SFBP1-G750-07 | 672 GPH | 12 V | 5.0 A | 5.0 A | 8.2' (2.5 m) | 3' (1 m) | 3/4" | 1.17/1.35 kg |
| SFBP2-G750-07 | 676 GPH | 24 V | 2.9 A | 3.0 A | 8.2' (2.5 m) | 3' (1 m) | 3/4" | 1.17/1.36 kg |
PERFORMANCE
750GPH 12VVoltage(V)
| Current(A)
| Flow
| Head(M)
| | GPH | LPH | | 12 | 2.6 | 690 | 2612 | 0 | | 12 | 2.6 | 680 | 2574 | 0.5 | | 12 | 2.7 | 620 | 2347 | 1 | | 12 | 2.7 | 560 | 2120 | 1.5 | | 12 | 2.8 | 430 | 1628 | 2 | | 12 | 2.8 | 0 | 0 | 2.5 |
| | 750GPH 24VVoltage(V)
| Current(A)
| Flow
| Head(M)
| | GPH | LPH | | 24 | 1.3 | 676 | 2558 | 0 | | 24 | 1.6 | 529 | 2002 | 0.5 | | 24 | 2.05 | 388 | 1468 | 1 | | 24 | 2.33 | 189 | 715 | 1.5 | | 24 | 2.53 | 80 | 303 | 2 | | 24 | 2.9 | 0 | 0 | 2.5 |
|
