BHD34.700
Product Details
Product Details
Product Details
TYPICAL APPLICATIONS
Marine; RV; toilet
DIMENSIONS
APPLICATION
STANDARD PUMP CONFIGURATIONS
| Model | Voltage | Open Flow | Dimensions | Impeller | Ports | Max Draw(A) |
| SFMP1-120-01 | 12V | 12.0/45.0 | 11.18"x5.01"x3.85" 284x127.5x98mm | Rubber & Copper | 1-1/2” MNPT 1" Hose Barb | 12.0 A |
| SFMP2-120-01 | 24V | 12.0/45.0 | 11.18"x5.01"x3.85" 284x127.5x98mm | Rubber & Copper | 1-1/2” MNPT 1" Hose Barb | 6.0 A |
PERFORMANCE
|
| Key | Description | Quantity |
| 1 | Inlet Cover | 1 |
| 2 | Screw 1 | 4 |
| 3 | Macerator Housing | 1 |
| 4 | Screw Nut | 1 |
| 5 | Chopper Blade Kit | 1 |
| 6 | Gasket | 2 |
| 7 | Wearplate, Large | 1 |
| 8 | Impeller | 1 |
| 9 | Wearplate, Small | 1 |
| 10 | Bearing Cover | 1 |
| 11 | Seal | 1 |
| 12 | Outlet Cover | 1 |
| 13 | Pump Body | 1 |
| 14 | Motor | 1 |
| 15 | Rubber Feet | 4 |
| 16 | Base plate Assembly | 1 |
| 17 | Screw 2 | 2 |
| 18 | Adjustment Cap | 1 |
SHIPPING INFORMATION
 | |
Unit Pump Weight | 4.55 lbs (2.07 kg) |
Selling Unit Size (L x W x H) | 13.78" x 5.19" x 4.33" (35.0 x 13.0 x 11.0 cm) |
Selling Unit Weight | 5.11 lbs (2.32 kg) |
Master Carton Size (L x W x H) | 24" x 13.30" x 9.92" |
Master Carton Qty | 8 pcs |
Master Carton Weight | 40.83 lbs (18.56 kg) |
