MORE FEATURES
| - 2 Year Warranty
- Meets or exceeds RoHS, SGS, and ISO standards
- Traditional operation by switch or float switch
- Entirely submersible - Snap-off strainer base for easy maintenance - Pump and switch are stand alone products - Sealed efficient,long life motors | - Run dry capable for normal workloads
- Quiet operation
- 110°F (43°C) temperature limits
- Stainless steel shaft - Anti-Airlock protection - Exclusive moisture tight seals - Marine grade blocked wiring |
TYPICAL APPLICATIONS
Marin 40ft, Medical, Pond, Water Research, Solar Water System, etc.
DIMENSIONS
STANDARD PUMP CONFIGURATIONS
| Model | Flow Rate | Voltage | Max Draw | Fuse Amps | Head | Wire Lead | Outlet Dia | N.W. / G.W. |
| SFBP1-G1500-01 | 1426 GPH | 12 V | 12.0 A | 12.0 A | 11.8' (3.6 m) | 3' (1 m) | 1-1/8" | 1.13/1.21 kg |
| | | | | | | | g |
PERFORMANCE
Voltage(V) | Current(A) | Flow | Head(M) | GPH | LPH | | OPEN | 5.8 | 1426 | 5396 | 0 | | 12 | 6.33 | 1255 | 4749 | 0.5 | | 12 | 6.95 | 888 | 3360 | 1 | | 12 | 7.25 | 745 | 2819 | 1.5 | | 12 | 8.05 | 589 | 2229 | 2 | | 12 | 9.85 | 321 | 1215 | 2.5 | | 12 | 10.42 | 201 | 761 | 3 | | 12 | 11.62 | 76 | 288 | 3.5 | | 12 | 12 | 0 | 0 | 3.6 |
| | oltage(V) | Current(A) | Flow | Head(M) | GPH | LPH | | OPEN | 3.13 | 1407 | 5324 | 0 | | 24 | 3.45 | 1211 | 4583 | 0.5 | | 24 | 4.15 | 865 | 3273 | 1 | | 24 | 4.77 | 724 | 2740 | 1.5 | | 24 | 5.03 | 577 | 2184 | 2 | | 24 | 5.58 | 305 | 1154 | 2.5 | | 24 | 6.15 | 188 | 711 | 3 | | 24 | 6.74 | 84 | 318 | 3.5 | | 24 | 6.9 | 0 | 0 | 3.6 |
|
